Xe nâng đứng lái RT20Pro

Technical data sheet for industrial truck acc. to VDI 2198

1KG=2.2LB 1INCH=25.4mm

Distinguishing mark

1.2

Manufacturer‘ type designation

RT15ST

1.3

Drive(electric,diesel,petrol,gas,main electric)

Battery

1.4

Type of operation(hand,pedestrian,,stand on,rider picker)

Stand on

1.5

Load capacity/rated load

Q (t)

1.5

1.6

Load center distance

C (mm)

500

1.8

Load distance,cenre of drive axle to fork

X(mm)

380

1.9

Wheelbase

y (mm)

1482

Weight

2.1

Service weight incl.battery

kg

3630

2.3

Axle loading,unladen front/rear

kg

2260/1370

2.4

Axle loading,fork advanced,laden front/rear

kg

840/4290

2.5

Axle loading,fork retraced,laden front/rear

kg

1960/3170

Tyres, chassis

3.1

Tyres(solid rubber,superelastic,pneumatic,polyurethane)

Polyurethane

3.2

Tyres size,front

ØxW(mm)

343×140

3.3

Tyres size,rear

ØxW(mm)

267×106

3.5

Wheels,number front/rear(x=driven wheels)

2/1x+2

3.7

Track width,rear

b11(mm)

1010/500

Dimensions

4.1

Mast/fork carriage tilt forward/backward

α/β (°)

3/5

4.2

Lowered mast height

h1(mm)

3398

4.3

Free lift

h2(mm)

2760

4.4

Lift height

h3(mm)

8000

4.5

Extended mast height

h4(mm)

8860

4.7

Overhead load guard（cab）height

h6(mm)

2330

4.19

Overall length

l1(mm)

2246

4.20

Length to face of forks

l2(mm)

1326

4.21

Overall width

b1(mm)

1130

4.22

Fork dimensions

s/e/l(mm)

35/100/920

4.25

Width over forks

b5(mm)

200/760

4.28

Reath distance

l4(mm)

560

4.31

Ground clearance

m1(mm)

80

4.34

Aisle width for pallets 800X1000 crossways

Ast(mm)

2695

4.35

Turning radius

Wa(mm)

1750

4.37

Length across wheel arms

l7(mm)

1855

Performance data

5.1

Travel speed,laden/unladen

km/h

9.5/9.5

5.2

Lift speed,laden/unladen

m/s

0.28/0.32

5.3

Lowering speed,laden/unladen

m/s

0.35/0.31

5.4

Reath speedm,laden/unladen

m/s

0.09/0.12

5.8

Max.gradient performance,laden/unladen

%

10/15

5.10

Service brake

Electromagnetic

Electric- engine

6.1

Drive motor rating S2 60 min

kW

5.5

6.2

Lift motor rating at S3 15%

kW

8.6

6.3

Battery acc.to DIN 43531/35/36 A,B,C,no

A,4Pzs

6.4

Battery voltage,nominal capacity K5

V/Ah

48/360

6.5

Battery weight

kg

680

Additional data

8.1

Type of drive control

Zapi

8.2

Operating pressure for attachments

(bar)

110

8.3

Oil volume for attachments

(l/min)

40

8.4

Sound level at driver's ear according to EN 12053

dB/(A)

＜70
